RJ35-SXXSWITCH UNIT
RJ35-SXX SWITCH UNIT is an expansion module to meet the needs of multi-channel DC resistance test and multi-channel battery resistance and voltage test. Through RJ35 series instrument control, it can realize up to 540 channels of DC resistance test or battery resistance and voltage test, improving the test efficiency. Final test results can be read directly from the RJ35 series header display or RS232 communication.
Main feature
Single channel test time (including channel switching time) minimum 185ms
With total voltage total resistance test function (less than 31 channels)
With single voltage, single resistance analysis function
A single scanning unit can be connected to a maximum of 108 test channels
Technical parameter
| Model | RJ35-SXX | |||
| Single channel corresponding minimum test time (RJ3563) | Super Fast | Fast | Slow speed | |
| 185ms | 206ms | 317ms | ||
| Single channel corresponding minimum test time (RJ3545) | Fast | Slow speed | ||
| 300ms | 500ms | |||
| Test wiring | Four-wire system | |||
| Number of supported channels | 1~540 channels (up to 108 channels for a single unit, up to 5 in series) | |||
| Maximum withstand voltage for single channel | 150V | |||
| Contact source | Manual trigger, communication trigger | |||
| Power supply | AC100V~240V, 50/60Hz | |||
| Exterior dimensions | Small chassis 45 channels and below | 220mm x 132mm x 400mm (W x H x D) without foot, foot height 15mm | ||
| Large chassis 46 channels and above | 445mm x 132mm x 400mm (W x H x D) without foot, foot height 15mm | |||
| Attachment | 1 manual, power cord (1.5 m), number depends on the number of cases, CN36 cable (1.5 m), number depends on the number of cases, 2 twisted-pair test wires, D-type connector 37P straight female welding wire and metal shell, number depends on the number of channels | |||
